Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: XR Solar
  • Model Number: XRE-110x100
  • Material: Monocrystalline Silicon
  • Size: 110x100
  • Number of Cells: 12
  • Max. Power: 1.62W
  • Optimum Operating Voltage(Vmp): 6v
  • Optimum Operating Current (Imp): 0.27A
  • Short Circuit Current (Isc): 0.277A
  • Open Circuit Voltage(Voc): 6.9V

Packaging & Delivery

Packaging Details carton packing, wooden packing, pallet
epoxy mini Solar Panel
Delivery Time two weeks after order confirmation

6V 270mA  Customized Epoxy Mini Solar Panel





Product Description











Features



1) High Module conversion efficiency, through superior manufacturing technology

2) 0 to +5W positive tolerance for mainstream products

3) Certified to withstand high wind loads and snow loads

4) Anodized aluminum is for improving corrosion resistance

5) Anti-reflective, Highly transparent, low iron tempered glass

6) Excellent performance under low light environment











Electrical Characteristics





Item No.XRE-110X100-6V270
Optimum Operating Voltage (Vmp)6V
Optimum Operating Current (Imp)0.27A
Open Circuit Voltage (Voc)6.9V
Short Circuit Current (Isc)0.277A
Maximum Power at STC (Pmax)1.62W
Cell  Efficiency15%
Operating Module Temperature   -40 °C to +85 °C
Maximum System Voltage  1000 V DC (IEC) / 600V DC (UL)
Maximum Series Fuse Rating   15 A
Power Tolerance   0/+5 %



STC:  lrradiance 1000 W/m2, module temperature 25 °C, AM=1.5;

Best in Class AAA solar simulator (IEC 60904-9) used, power measurement uncertainty is within +/- 3%







Mechanical Characteristics



Solar Cell
Mono-crystalline silicon solar cell
No. of Cells12pcs
Dimensions110x100mm
Weight40g
